Kona Remote 160 DL Electric Mountain Bike

The Kona Remote 160 DL is a full suspension electric mountain bike designed for trail and enduro riding. Built around a durable aluminum frame, it features 160 mm of front and rear suspension travel and a Shimano mid-drive motor system. The Remote 160 DL balances electric assistance with stable handling geometry for technical terrain, long climbs, and sustained trail use.

This model is configured for riders seeking a capable e-MTB with consistent power delivery, controlled suspension performance, and components suited for demanding trail conditions.

Key Features

• Full suspension electric mountain bike platform

• Shimano mid-drive motor with integrated battery

• 160 mm front and rear suspension travel

• Aluminum frame designed for e-MTB use

• Hydraulic disc brakes with large rotors

• 29-inch wheels for stability and rollover

Full Specifications

Frame and Suspension

• Frame: Kona 6061 Aluminum e-MTB frame

• Rear Travel: 160 mm

• Fork: RockShox Yari RC

• Fork Travel: 160 mm

• Rear Shock: RockShox Deluxe Select Plus

• Head Tube: Tapered

• Rear Axle Spacing: Boost 148 × 12 mm

• Front Axle Spacing: Boost 110 × 15 mm

Motor and Battery

• Motor: Shimano STEPS EP8 mid-drive

• Maximum Torque: 85 Nm

• Battery: Shimano internal battery, 630 Wh

• Charger: Shimano

• Assist Modes: Eco, Trail, Boost

Drivetrain

• Shifter: Shimano Deore

• Rear Derailleur: Shimano Deore

• Cassette: Shimano Deore 10–51T, 12-speed

• Crankset: Shimano e-MTB crankset

• Chain: Shimano 12-speed

• Bottom Bracket: Shimano STEPS

Brakes

• Brake System: Shimano hydraulic disc brakes

• Front Rotor: 203 mm

• Rear Rotor: 203 mm

Wheels and Tires

• Rims: WTB ST i30 TCS

• Hubs: Shimano Boost

• Spokes: Stainless steel

Tires

• Front Tire: Maxxis Minion DHF 29 × 2.5 WT

• Rear Tire: Maxxis Minion DHR II 29 × 2.4 WT

• Tubeless Ready: Yes

Cockpit

• Handlebar: Kona aluminum

• Stem: Kona aluminum

• Grips: Kona Key Grip

• Headset: FSA

Seat and Post

• Seatpost: Dropper post, 31.6 mm

• Saddle: Kona Trail

• Seat Clamp: Kona

Sizing

Available in multiple sizes to fit a wide range of riders.
Contact us if you need help choosing the correct size.

Ready to Ride?

Order your Remote 160 DL today and experience one of the most respected mountain bikes ever made.
